CW-PAG-R10-Switch with 8+2 Gigabit PoE ports
Network Infrastructure
Switch with 8+2 Gigabit PoE ports
- Port Configuration: 8 PoE ports (1 port ≤ 30W, IEEE 802.3af/at) + 2 Gigabit SFP ports (supports single-mode 20km / multimode 550m fiber)
- Power Capacity: 120W total PoE power supply, capable of fully powering 4 sets of 30W devices
- Performance: Unmanaged plug-and-play, 10 Gbps backplane bandwidth, 20 Gbps switching capacity, supports distances up to 250 meters (Cat5e+)
- Design: Metal enclosure (200 x 120 x 44 mm), fanless, silent operation, IP30 dust protection rating, supports DIN rail mounting
- Reliability: 6 kV surge protection, overcurrent/short-circuit/overheat protection, wide industrial temperature range (0°C to 50°C), 2-year warranty
$22.00 - $44.00
Gigabit Uplink 8+2-Port POE Adapter Technical Specifications (120W)
1 – Basic Specifications
- Model: 8+2-Port Gigabit Uplink POE Switch (8 Ethernet Ports + 2 Fiber Ports)
- Certification Standards: Complies with Chinese National Standard (GB/T-120W), 120W Full POE Power (2-Year Warranty)
- Uplink Speed: 2 Gigabit SFP optical ports (optional single-mode/multi-mode modules)
- Management Type: Unmanaged (Plug-and-Play)
2. Port Configuration
- Electrical Ports: 8 configurable RJ45 10/100/1000 Mbps ports.
- Single-port PoE power ≤ 30W (IEEE 802.3at standard)
- Total POE power for the entire device is 120W (can simultaneously power four 30W devices at full load)
- Fiber Ports: 2 Gigabit SFP uplink ports (support hot-swap, with optional transmission distances of 20 km or 550 m)
3 – Performance Specifications
- Backplane bandwidth: 10 Gbps (non-blocking switching architecture)
- Switching capacity: 20 Gbps (full-line-rate forwarding)
- Transmission distance
- Power outlet ≤ 250 meters (Cat5e or higher cable)
- Fiber Ports Supports single-mode up to 20 km and multi-mode up to 550 m (requires corresponding optional modules)
- VLAN support: Ports do not support VLANs (basic Layer 2 switch)
4 – Power and Power Efficiency
- Power Input: AC 100–240 V (wide-range input), external power adapter
- Total power consumption: ≤120W at full POE load, <8W in standby
- PoE Protocol: Supports IEEE 802.3af/at (automatic detection of PD devices)
5 – Physical Specifications
- Dimensions: 200 mm x 120 mm x 44 mm (metal housing, dual desktop/rack mounting)
- Weight: 1 kg (including power adapter)
- Cooling Design: Fanless passive cooling, operating noise level 0 dB
- Protection Rating: IP30 (Dust-proof, Electrostatic Discharge (ESD) protection)
6 – Environmental Adaptability
- Operating temperature: 0°C to 50°C (optional -40°C to 75°C wide industrial temperature range)
- Humidity range: 10%–90% relative humidity (no condensation)
- Installation: Supports desktop mode/DIN rail mounting
7. Safety and Reliability
- PoE Protection: Overcurrent/Short-Circuit Protection/Automatic Over-Temperature Protection
- Surge Protection: 6 kV lightning protection for Ethernet ports
- Warranty: Two-year limited warranty (including POE module)
