Fiber Adapter

Switch with 8+2 Gigabit PoE ports

• Port Configuration: 8 PoE ports (1 port ≤ 30W, IEEE 802.3af/at) + 2 Gigabit SFP ports (supports single-mode 20km / multimode 550m fiber)
• Power Capacity: 120W total PoE power supply, capable of fully powering 4 sets of 30W devices
• Performance: Unmanaged plug-and-play, 10 Gbps backplane bandwidth, 20 Gbps switching capacity, supports distances up to 250 meters (Cat5e+)
• Design: Metal enclosure (200 x 120 x 44 mm), fanless, silent operation, IP30 dust protection rating, supports DIN rail mounting
• Reliability: 6 kV surge protection, overcurrent/short-circuit/overheat protection, wide industrial temperature range (0°C to 50°C), 2-year warranty

• Performance exceeds the Cat.6 requirements specified in ANSI/TIA 568-C.2 and ISO/IEC 11801 standards.

• Gold-plated pins improve contact performance, prevent surface oxidation and extend service life.

• Unique cable protection cover secures core wires firmly, provides effective dustproof performance, and integrates cable crimping function.

• Compact structural design offers ample routing space for cables inside mounting boxes.

• Specially engineered staggered pin layout effectively improves Near-End Crosstalk (NEXT) margin.

• Performance exceeds the Cat.5e requirements specified in ANSI/TIA 568-C.2 and ISO/IEC 11801 standards.

• Integral die-cast metal construction provides full 360° shielding.

• Compact structural design delivers ample cable routing space inside mounting boxes.

• Split crossbar design effectively controls cable untwist length and enables quick tool-free termination installation.

• Specially engineered spatial layout of gold pins effectively improves Near-End Crosstalk (NEXT) margin.
